Key Specifications / Features
Our 21 kW AC EV Charging Pile Supplier offers versatile and powerful AC EV chargers suitable for both wall-mounted and pedestal installations. These chargers operate within a frequency range of 45–55 Hz and support a wide voltage range of 50–1000 V, with a current rating of 32 A. They are equipped with OCPP 1.6 protocol for seamless network integration and feature IP55 protection against dust and water ingress. The chargers come with multiple connector options, including GB/T, Type 1, and Type 2, ensuring compatibility with various electric vehicles.
- Model No.: DAEVC-20250929-ACEV-01
- Hits: 15
- Categories: AC EV Charger
- Tags: 21 kW EV Charger, AC EV Charger, Pedestal EV Charger
Detail Information
Product Name: 21 kW AC EV Charging Pile
Rated Power: 21 kW
Frequency: 45–55 Hz
Output Voltage: 50–1000 V
Input Voltage: 380 V ± 20%
Input/Output Current: 32 A
Screen: 4.3-inch Touch Screen
Plug/Connector Type: GB/T / Type 1 / Type 2 / Tesla
Cable Length: 5 m (OEM Available)
Communication Protocol: OCPP 1.6
Installation: Wall Mounted / Pedestal (Optional)
Charging Method: RFID / Password / VIN / App (Optional)
Performance & Environmental Specifications
Efficiency: ≥95%
Operating Temperature: -25°C to +50°C
Storage Temperature: -40°C to +70°C
Atmospheric Pressure: 70–106 kPa
Altitude: ≤2000 m
Protection Grade: IP55, IK10
Applications: Home, commercial, and public AC EV charging
